XB-TS23E01-AT15

圆柄摇杆拨动开关

1. 额定负荷: DC 12V 30V  0.3A  0.5A

2. 接触阻抗: ≤30mΩ

3. 绝缘阻抗: ≥100mΩ

4. 耐焊温度: 250±5°5s

5. 使用寿命: 10,000 cycles

6. 使用温度: -25 ℃ to 80 ℃

7. 使用湿度: ≤85% RH

8. 操作力 : 250gf

9.手柄长度:5-15mm  可定制

10.电路功能：2档 3档

11.结构功能：自复位与不复位

产品用途应用：电器、照明、数码产品、安防、计算机电脑、通讯产品、家用电器、运动器材。

品牌：溪榜电子

Round handle rocker toggle switch

1. Rated load: DC 12V 30V 0.3A 0.5A

2. Contact impedance: ≤ 30m Ω

3. Insulation impedance: ≥ 100m Ω

4. Welding resistance temperature: 250 ± 5 ° 5s

5. Service life: 10000 cycles

6. Operating temperature: - 25 ℃ to 80 ℃

7. Operating humidity: ≤ 85% RH

8. Operating force: 250gf

9. Handle length: 5-15mm, customizable

10. Circuit function: second gear and third gear

11. Structure function: self reset and non reset

Application: electrical appliances, lighting, digital products, security, computers, communication products, household appliances, sports equipment.

Brand: Xibang Electronics
